| KESG-04 | KESG-06 | KESG-08 | KESG-17 | |
|---|---|---|---|---|
| Carrier | 6-10 ton | 10-15 ton | 16-22 ton | 31-37 ton |
| Cylinder Pressure | 350 bar | 350 bar | 350 bar | 350 bar |
| Cylinder Oil Flow | 15-30 l/min | 30-65 l/min | 40-80 l/min | 95-165 l/min |
| Check Valve | N | Y | Y | Y |
| 360° Rotation Pressure | 100 bar | 140 bar | 140 bar | 140 bar |
| Rotation Oil Flow | 8-12 l/min | 12-20 l/min | 12-20 l/min | 28-40 l/min |
| Rotation Speed | 10-15 tr/min | 10-15 tr/min | 10-15 tr/min | 10-15 tr/min |
| Force | 25000 N | 40000 N | 50000 N | 93000 N |
| Volume | 147 L | 395 L | 470 L | 1080 L |
| Weight | 370 kg | 745 kg | 950 kg | 2100 kg |
