| | KES200 | KES300 | KES400 |
|---|
| Operating Weight | 129kg (284 lb) | 150kg (331 lb) | 361kg (796 lb) |
| Required Oil Flow | 20-40 l/min (5.28-10.7 gal/min) | 25-50 l/min (6.6-13.2 gal/min) | 36-60 l/min (9.5-15.85 gal/min) |
| Working Pressure | 90-100 bar (1305-1450 psi) | 90-120 bar (1305-1740 psi) | 110-140 bar (1596-2030 psi) |
| Impact Rate | 500-1000 bpm | 500-1000 bpm | 500-900 bpm |
| Cup Diameter (Standard) | 150mm (5.9 inch) | 175mm (6.89 inch) | 200mm (7.87 inch) |
| Hose Diameter | ½ inch | ½ inch | ½ inch |
| Excavator Weight | 1.6-2.6 ton (3527-5732 lb) | 2-4 ton (4409-8820 lb) | 3.6-7 ton (7937-15433 lb) |
