| Body Weight | 2823 kg |
|---|---|
| Total Weight (Side / Top / Box) | 5418 kg / 5810 kg / 5823 kg |
| Length (Side / Top / Box) | 3596 mm / 4030 mm / 4043 mm |
| Width (Side / Top / Box) | 755 mm / 755 mm / 755 mm |
| Height (Side / Top / Box) | 1690 mm / 908 mm / 940 mm |
| Operating Pressure | 200–240 / 200–240 kg/cm² |
| Oil Flow Range | 290–360 / 280–360 l/min |
| Impact Frequency | 150–200 / 250–320 bpm |
| Hose Diameter | 1¼ inch |
| Tool Diameter | 195 mm |
| Suitable Carrier | 50–65 ton |
