| | KES FC08D | KES FC15D | KES FC20D |
|---|
| Outline Dimension A | 1155mm (45.47 inch) | 1815mm (71.45 inch) | 2008mm (79.05 inch) |
| Outline Dimension B | 550mm (21.65 inch) | 850mm (33.46 inch) | 1000mm (39.37 inch) |
| Outline Dimension C | 240mm (9.45 inch) | 420mm (16.53 inch) | 480mm (18.90 inch) |
| Outline Dimension D | 486mm (19.13 inch) | 662mm (26.02 inch) | 732mm (28.82 inch) |
| Weight | 536kg (1181.7 lb) | 1895kg (4177.8 lb) | 2550kg (5621.8 lb) |
| Shear Working Pressure | 176.52-245 bar (2560-3556 psi) | 294-343 bar (4267-4978 psi) | 294-343 bar (4267-4978 psi) |
| Shear Working Flow | 50-100 l/min (13.20 gal/min) | 140-240 l/min (37-63.40 gal/min) | 180-240 l/min (47.55-63.40 gal/min) |
| Rotating Working Pressure | 59-88 bar (853-1280 psi) | 137-157 bar (1991-2277 psi) | 137-157 bar (1991-2277 psi) |
| Rotating Working Flow | 30-50 l/min (7.92-13.20 gal/min) | 40-60 l/min (10.56-15.85 gal/min) | 40-60 l/min (10.56-15.85 gal/min) |
| Cutting Oil Port | G3/4” | G1” | G1” |
| Rotating Oil Port | G3/8” | G3/8” | G3/8” |
| Suitable Carrier | 5-10 ton (11023-22046 lb) | 17-25 ton (37478-55115 lb) | 26-35 ton (57320-77162 lb) |
| Working Mode | Mechanical or hydraulic type, 360° free rotation |
